Spind UPVC Pipes

These pipes are compiled with MS 1063 which intended to be used for soil and waste discharge pipe work for conveyence of domestic water waste (low and high temperature), ventilating pipe work and rainwater pipe work within building structure. this standard is equivalent to BS 5255, BS 4514, BS EN 1401 and BS EN 1320.

Specification of Soil, Waste and Ventilating (S.W.V.) Pipes
Colour White
Length 4m or 5.8m
Type of Joint Solvent Cement Weld Joint

*UPVC Pipes are only available for export market.

Size & Range

Nominal SizeMean Outside Diameter (mm)Wall Thickness
BBD
In.mmMinMaxMinMaxMinMax
13636.236.53.03.5--
14342.843.13.03.5--
25655.856.13.03.5--
38282.482.83.03.53.03.5
4110110.0110.33.23.83.23.8
6160160.0160.43.23.83.23.8
8200200.0200.53.94.54.95.6
10250250.0250.54.95.66.27.1
12315315.0315.66.27.17.78.7

Application area code:

Code “B” = Application for compenents intended for use above ground inside the buildings, or for components outside buildings fixed onto the wall.
Code “BD” = Application for components intended for above ground use for both inside the buildings, or components outside buildings fixed onto the wall and burried in building structures.
